– WiFi 6 băng tần 5 GHz (4x4), WiFi 4 băng tần 2.4 GHz (4x4)
– Tốc độ thông lượng tổng hợp 3.0 Gbps
– Kiểu ăng-ten nằm ngang, nghiêng xuống để mở rộng vùng phủ sóng
– (1) Cổng GbE RJ45 (PoE In)
– Cấp nguồn bằng PoE+
Dimensions | Ø220 x 48 mm (Ø8.66 x 1.89″) |
Weight | Without Mount: 800 g (1.76 lb) |
With Mount: 930 g (2.05 lb) | |
Enclosure Material | Plastic |
Mounting Material | SGCC Steel |
Weatherproong | IP54 |
HARDWARE | |
Processor Specs | Dual-Core® Cortex® A53 at 1.35 GHz |
Memory Information | 512 MB |
Management Interface | Ethernet In-Band |
Networking Interface | (1) 1 Gbps Ethernet RJ45 |
Buttons | Factory Reset |
LEDs | RGB |
Power Method | 802.3at PoE, Passive PoE (48V) |
Power Supply | 802.3at PoE; 48V, 0.65A PoE Adapter (Not Included) |
Supported Voltage Range | 44 to 57VDC |
Max. Power Consumption | 16.5W |
Max. TX Power |
|
2.4 GHz | 26 dBm |
5 GHz | 26 dBm |
MIMO |
|
2.4 GHz | 4 x 4 |
5 GHz | 4 x 4 |
Throughput Speeds |
|
2.4 GHz | 600 Mbps |
5 GHz | 2400 Mbps |
Antenna Gain |
|
2.4 GHz | 4 dBi |
5 GHz | 5.5 dBi |
Mounting | Wall/Ceiling (Kits Included) |
Operating Temperature | -30 to 60° C (-22 to 140° F) |
Operating Humidity | 5 – 95% Noncondensing |
Certifications | CE, FCC, IC |
SOFTWARE | |
Wi-Fi Standards | 802.11a/b/g |
Wi-Fi 4/Wi-Fi 5/Wi-Fi 6 | |
Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
BSSID | 8 per Radio |
VLAN | 802.1Q |
Advanced QoS | Per-User Rate Limiting |
Guest Trafc Isolation | Supported |
Concurrent Clients | 300+ |
SUPPORTED DATA RATES (MBPS) | |
802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b | 1, 2, 5.5, 11 Mbps |
802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n (Wi-Fi 4) | 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40) |
802.11ac (Wi-Fi 5) | 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
802.11ax (Wi-Fi 6) | 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160) |
